Slow loading of embedded apps can be stressful for users. App users will not be able to work and will have a negative impression of your app. To make matters worse, if it doesn’t load at all, you’ll have to spend all your time checking the report to determine the cause.
App load delays and failures are primarily due to Shopify’s app authentication. In this article, I’ll show you how embedded app authentication works and new solutions to this frustrating problem.
Table of Contents
How The Embedded App Is Loaded
When the merchant clicks the link to load the app, it will appear on the screen after a few seconds. What is happening under the surface at this time?
First, Shopify creates an iframe on the admin screen and sets the URL of the app. When the browser makes a request to the app, it will contain some cookies previously set by the app. The session information contained in this cookie tells the app who is accessing it.
Sometimes there are no cookies or the session does not contain user information. In this case, the app Shopify of OAuth redirects the user to the service, OAuth is making sure that the user has to install the app, then redirects the user back to the app. At this time, the user recognition information is passed to the app. The app saves your user information and links it to a session cookie. As a result, subsequent interactions will occur without the involvement of the OAuth service.
Now that the app can determine who the user is, it can load based on user-specific information.
What Causes Slow App Loading?
The process of redirecting to the OAuth server is slow. Redirection cannot be done inside the iframe because it sets a session cookie. Instead, the entire browser is redirected. All the redirects required for OAuth simply redirect the user to the Shopify admin and embedded app pages at the end. In many cases, browser redirects are seamless to the user. However, due to the number of redirects required and the jump back and forth between the frame and the top frame of the browser, users will find the app loading slow and undirected.
The overall flow is as follows.
1 Embedded iframe: Load app
2 Top Frame: App redirects to Shopify OAuth
3 Top Frame: Shopify OAuth redirects to the app
4 Top frame: Load the app, recognize that it is outside the iframe, and redirect to the admin
5 Loading top frame admin
6 Embedded iframe: Load app
Performance suffers at each stage, which in turn results in a disappointing UX. The overall load time has increased to as much as 10 seconds, which can be very long for users who are not patient.
Causes When The App Does Not Load At All
Over the past few years, browser vendors have focused on protecting user privacy. This is good for users because they have control over how the data is handled. Browser vendors, in particular, have sought to stop tracking across sites.
Neither Shopify nor related apps are the “trackers” that browser vendors are trying to block. However, the technology we use to enhance embedded apps ( iframes ) is the same technology used for many cross-site tracking. As a result, browser-implemented cross-site tracking regulations, such as Safari’s ITP ( Intelligence Tracking Prevention ), are hampering the functionality of the Shopify app.
If the user sees this error, it’s likely that a third-party cookie is a problem.
There are ways to get around regulations like Safari’s ITP, but they are difficult to implement, force unwanted UX, and cannot cover all cases.
How To Fix Read Delays And Third Party Cookie Errors
Shopify is introducing a new way to load apps. Instead of using session cookies to retrieve and store user information, you can use session tokens. This session token is a secure packet containing information about the user accessing the app. Like a session cookie, this token conveys your information to your app.
When the app loads, the front end gets a session token through the App Bridge. This token will be included in the request to the app’s backend and will provide all the user-specific information that the app needs. This means that in most cases, your app will only perform an OAuth redirect on the first install and will not need to store your user information in a cookie. Instead, the app can use the session token after the initial installation.
Comparison of old and new embedded application loading flow
This mechanism is significantly more reliable and faster than the cookie-based approach. Apps that use App Bridge authentication can load up to 4 times faster and do not cause cookie-related loading errors. The following video compares how fast an embedded app with App Bridge authentication loads.
If you want to know more about implementing session tokens, please visit our detailed tutorial.
To Improve The User Experience
Load speed and stability issues frustrate users and reduce app utilization. Encouraging restrictions on third-party cookies in browsers only exacerbates the problem.
Shopify’s new authentication method, an embedded app solution, can solve both issues at once while improving the app’s user experience.
